80*80mm 2.5m Hydraulic Crimped Wire Machine Low Noise

Place of Origin HEBEI, CHINA
Brand Name DIAOZHUO
Certification CE ISO9001
Model Number DZ1300 DZ1600 DZ2000
Minimum Order Quantity 1SET
Price variable
Packaging Details woodencase and plastic bags
Delivery Time 20-30 WORING DAYS
Payment Terms L/C, D/P, T/T
Supply Ability 2-3SET ONE MONTH

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Could Produte Roll And Panel Specification Q235
Width 2m, 3m, 4m HS Code 7308900000
Weave Method Flat-Topped Curved Weight 1800kg
Dimensions 3200*2500*1700m Voltage 380V 50HZ
COLOR White And Blue
Highlight

80*80mm Hydraulic Crimped Wire Machine

,

2.5m Hydraulic Crimped Wire Machine

,

80*80mm Wire Crimping Machine

Leave a Message
Product Description

Q235 5-12mm Hydraulic Fully Automatic Crimped Wire Mesh Weaving Machine

Hydraulic crimped wire machine is powered by high power rate electric machine and hydraulically controlled in knitting, changing headless, matting. It has the characteristics of stable performance, low noise, high knitting efficiency and sooth knitting mesh. This machine is mainly used for knitting big diameter mine sieving mesh with 4.0mm-12mm diameter and 2.0m width. Its products are mainly used in big mines, and coal fields to sieve and filter.

Main parameter of Semi-automatic Crimped Wire Mesh Machine:
Weaving width:
0.9-2.5m
Wire diameter:6-12mm
Mesh:3*3-80*80mm
Quality certification:ISO:9001:2008

80*80mm 2.5m Hydraulic Crimped Wire Machine Low Noise 0

Quick Details

Type crimped wire mesh making machine Applicable Industry Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Retail, Construction works
Condition New Place of Origin HeBei,China
brand Name ANPING DIAOZHUO Usage crimped wire mesh making
Voltage 380V 50HZ Dimensions 3200*2500*1700m
Weight 2TONS Certification SGS ;CE
Warranty 1 Year COLOR White and blue
Wire diameter 1.5-5mm Mesh width 1000-4000mm
Mesh size 20*20-200*200mm Raw materials galvanized steel wire PVC wire
Control system Manual speed 35-40times/min
Series crimped wire mesh making machine Power 3KW




80*80mm 2.5m Hydraulic Crimped Wire Machine Low Noise 180*80mm 2.5m Hydraulic Crimped Wire Machine Low Noise 2



Crimped Wire Mesh Machine Main Parameters:

Item Automatic Crimped
Wire Mesh Machine

Semi-auto Crimped
Wire Mesh Machine
Hydraulic Crimped Wire Mesh Machine
Wire Diameter 0.4-2.0mm 2-6.0mm 5.0-12.0mm
Mesh Size 0.8*0.8mm-15*15mm >4mm >10mm
Weaving Width 1300/1600/2000mm 2000/2500mm 2000/2500mm
Motor 3.0KW 4.0KW 5.5KW
Speed 30-50times/min 35-40times/min 15-20times/min

Item Automatic Crimped
Wire Machine
Semi-auto Crimped
Wire Machine
Hydraulic Crimped Wire Machine
Wire Diameter 0.4-2.0mm 2.0-6.0mm
5.0-12.0mm
Mesh Size 0.8*0.8mm-15*15mm >4mm >10mm
Motor power 2.2KWA 3.0KWA 1.5KWA 4KWA 2.2KWA
Speed Control by Speed governor



80*80mm 2.5m Hydraulic Crimped Wire Machine Low Noise 380*80mm 2.5m Hydraulic Crimped Wire Machine Low Noise 480*80mm 2.5m Hydraulic Crimped Wire Machine Low Noise 5



Our machines could produce wire diameter range from 0.4 to 12 mm and width 1000 - 2500 mm 3 series,10kinds specifications crimped wire mesh machine . wire crimping machines

vibrating screen making machine

Our machines could produce every kind of high quality common curl type, plain crimped, intermediate crimped, lock crimped, flat top crimped.

crimped mesh machine manufacturer

This series of machine widely used for every technical-net, warehouse fence mesh, vibrating screen, wall net building etc.


Advantage:
1.It is suitable to do all kinds of material grade,More harder more better.
2.Reasonable design,no minimum order quantity request.No defective products.
3.Crimping wheel is double beating and double annealed:CNC wire-electrode cutting.To keep the uniform aperture.
4.Every machine is 100% done adjustment in factory to show both video and instruction to teach the staff how to do.Generally one week is enough to handle the machines skilled.

Packaging & Shipping

Packing: waterproof materials or wooden case(if within spare parts),also as customized.

Shipping: Within 30 days after we receive the advance payment


Our Services

Guarantee: one year, during this year, any broken parts caused by the quality, we can offer free,

after this year can offer with the lowest cost.

For the machine we offer video and operation manufal , if need, we can offer engineer oversea install and training, all the charge and fee also the salary of engineer will pay for by the buyer, techinical support all machine life free.
