Rebar Ribbed Steel Cold Rolling Mill Machine 150m/min 16mm 80kw
| Place of Origin | HEBEI, CHINA |
|---|---|
| Brand Name | DIAOZHUO |
| Certification | CE ISO9001 |
| Model Number | DZ-YL14 DZ-YL-11 DZ-YL-4 |
| Minimum Order Quantity | 1set |
| Price | variable |
| Packaging Details | with water-proof film covered or at customer's request |
| Delivery Time | 30-40days |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Cold Roling Twist Wire Making Machine | Services | 3 Years |
|---|---|---|---|
| Wire Diameter | 4 -12mm | Outlet Wire | 4 -6 Mm |
| Speed | Max 150m/min | Engineer | Available To Service Machinery Overseas |
| Highlight | 150m/min Cold Rolling Mill Machine,16mm Cold Rolling Mill Machine,80kw Cold Rolling Mill Machine |
||
Product Description
Cold Rolling Wire Drawing Screw Thread Line , Rebar Bar Ribbed Steel Cold Rolling Machine
(1) Introduction of Rebar/Bar Ribbed Steel Cold Rolling Machine
1 Derusting Machine
The machine is close type, there have three rotary wheels inside, we could adjust it up and down, it is easier for the raw materials installation, we could put the wire rod inside, then adjust the wheels.
2. Rolling mill
The rollers’ angle should be 120°, at the same center, first rolling mill is mainly for reducing the diameter, second set of rolling mill is for making the rebar,
3. Plate Machine
The machine is with electromagnetic motor, it offer the power for the whole line, the motor speed could be adjusting, it will change the rolling speed.
4. Stress-Relieving Machine
This machine is mainly for reducing the machine hardness.
5. The Wire Drawing Machine matches the moment type motor, the mainly spare parts is the wire wheel
6. Straight Machine and Cutter
(2) Parameters of Rebar/Bar Ribbed Steel Cold Rolling Machine
| Model | 15000T | 20000T | 30000T |
| Power | 37.5kw | 66kw | 80kw |
| Max input wire diameter | 13.5mm | 14mm | 14mm/16mm |
| Output wire diameter | 4-12mm | 4-13mm | 4-14mm |
| Speed | 75m/min | 120m/min | 150m/min |
| Ribbed machine type | 150 | 180 | 180 |
| Recoiler weight | 1T | 1T | 1T or 2T |
| Weight | 4T | 6T | 7.5T |
| Working dimension | 16-20 | 16-20 | 16-20 |
Packing:
One 20ft container/Set
Package: Stretch Film or Pallet
Main Farm Fence Wire Machinery: 1 Unit
Coil Holder: Several Units
Tool Cabinet: 1 Unit
Spare Parts: Several Units
Payment:30% TT for advance payment, 70% TT after the copy of B/L.
services:
1. Farm Fence Wire Machinery Warranty: One Year.
2. Enough spare parts of machines could be supplied.
3. All machines were tested and adjusted before delivery.
4. Engineers available to service machinery overseas: Worker-training, installation.etc.
5. 24 hours technical support by e-mail or calling service.
