Durable Biggest Perforated Metal Machine 2mm Hydraulic Overload Protection
| Place of Origin | HEBEI, CHINA |
|---|---|
| Brand Name | DIAOZHUO |
| Certification | CE ISO9001 |
| Model Number | DZ-CKW250 DZ-CKW2000 DZ-CKW1500 |
| Minimum Order Quantity | 1set |
| Price | variable |
| Packaging Details | with water-proof film covered or at customer's request |
| Delivery Time | 20-30 days |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 5 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Engineer | Available To Service Machinery Overseas | Speed | 220 Mesh/min |
|---|---|---|---|
| The Precision Of Hole-punching | 0.1mm | Product Name | Perforated Metal Machine |
| Thickness Sheet | As Required | Width | As Request |
| Power | 380V 50Hz | ||
| Highlight | ISO9001 Perforated Metal Machine,Perforated Metal Machine 2mm,2mm Perforated Punching Machine |
||
Product Description
CNC Precise And Durable Biggest Thickness 2mm Diaozhuo Perforated Metal Machine
The features of the perforated metal machine:
A. Welded steel frame, high strength.
B. Equipped with hydraulic overload protection.
C. Drive and lock the precision lead screw controlled by servo motor.
D. Break point continues processing function
E. Display working time and work piece processing quantity
The punching mesh is to punch large and small holes on different materials. The round hole is a common hole type in the punching sheet,which is very popular in the market.Usually, galvanized steel sheets, stainless steel sheets, copper sheets, aluminum sheets, nickel sheets, and alloy sheets are used as raw materials. The characteristics of the circular hole punching mesh:stamped; its performance is resistant to bending, anti-aging,rust,and versatile;the mesh surface is smooth and durable.The punching mesh is made of sheet metal and punched by punching machine. The punching mesh is widely used in the market.
Please check the details about the machine:
| Model | DZ31G-80 | DZ31G-125 | DZ31G-160 | DZ31G-200 |
| Nominal Force(KN) | 800 | 1250 | 1600 | 2000 |
| Nominal Stroke(MM) | 2 | 3 | 3 | 3 |
| Slide Stroke(MM) | 30 | 30 | 30 | 30 |
| SPM(MIN) | 160-280 | 160-240 | 160-220 | 150-200 |
| Max Die Height(MM) | 360 | 400 | 400 | 420 |
| Die Height Adjustment(MM) | 50 | 50 | 50 | 50 |
| Boster(F.B*L.R*T)(MM) | 550*980 | 600*1180 | 700*1380 | 800*1550 |
| Boster Opening(F.B*L.R)(MM) | 500*950 | 550*1050 | 600*1250 | 650*1450 |
| Between Columns(MM) | 1000 | 1200 | 1400 | 1600 |
| Motor Power(KW) | 11 | 18.5 | 22 | 30 |
| Air Pressure(MM) | 0.5 | 0.5 | 0.5 | 0.5 |
| Net Weight(KG) | 9000 | 11500 | 15000 | 19000 |
